Description
Processor generation : AMD Ryzen Embedded V1000 Series
Processor model : V1500B
Processor frequency : 2.2 GHz
Processor threads : 8
Processor manufacturer : AMD
Processor family : Ryzen Embedded
Processor cores : 4
Flash memory : 5000 MB
Maximum RAM supported : 64 GB
Memory slots : 2
Internal memory type : DDR4
Memory form factor : SO-DIMM
ECC : Yes
Internal memory : 8 GB
Chassis type : Tower
Number of fans : 3 fan(s)
Fan diameter : 9.2 cm
Fan diameter 2 : 6 cm
LED indicators : LAN, USB, HDD, Power, Status, SSD
Cable lock slot type : Kensington
Cooling type : Active
Cable lock slot : Yes
Product colour : Black
Power consumption (HDD standby) : 21.9 W
AC input voltage : 100-240 V
AC input frequency : 50/60 Hz
Power consumption (typical) : 45.898 W
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 70 °C
Operating temperature (T-T) : 0 – 40 °C
Height : 180.2 mm
Weight : 6.4 kg
Depth : 279.6 mm
Width : 264.3 mm
Package weight : 7.3 kg
iSCSI support : Yes
Load balancing system : Yes
DHCP server : Yes
Dynamic DNS (DDNS) : Yes
WLAN adapter supported : Yes
Jumbo frames support : Yes
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Ethernet LAN data rates : 2500
Backup function : Yes
Browser supported : Apple Safari (latest version), Google Chrome (latest version), Microsoft Edge (latest version), Mozilla Firefox (latest version)
Disk scan : Yes
Hot spare : Yes
Backup features : USB drive, iSCSI LUN, Cloud
Built-in FTP server : Yes
Access Control List (ACL) : Yes
S.M.A.R.T. support : Yes
Share folder : 512
Third-party support : Yes
Snapshot : Yes
Buzzer : Yes
Share folder access right management : Yes
System log : Yes
Number of users : 4096 user(s)
Device class : Small & Medium Business
Management protocols : SNMPv2/3
Type : NAS
Security algorithms : 256-bit AES, SNMPv3, SSH, SNMPv2, HTTPS, FIPS 140-2
On/off switch : Yes
Reset button : Yes
Web-based management : Yes
Power cables quantity : 2
Number of screws : 36
Cables included : LAN (RJ-45)
Operating system installed : QNAP QTS
Server operating systems supported : Windows Server 2019, Windows Server 2012, Windows Server 2022, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016
Other operating systems supported : UnixWare, Solaris 10, Citrix
Linux operating systems supported : Ubuntu 14.04, SUSE Linux Enterprise Desktop 12, CentOS 7.0
Operating system version : 5.2.5
Windows operating systems supported : Windows 11, Windows 10, Windows 8, Windows 7
Mac operating systems supported : Mac OS X 10.10 Yosemite
Storage drive sizes supported : 2.5, M.2, 3.5"
Online RAID migration : Yes
Storage drive capacity : 0 GB
Online RAID expansion : Yes
Supported file systems : exFAT, ext4, HFS+, FAT32, ext3
Storage drives installed : No
Total installed storage capacity : 0 TB
Disk roaming : Yes
Hot-swap drive bays : Yes
Installed storage drive type : No
RAID levels : 60, 1, 6, 10, 50, 0, 5, JBOD
Supported storage drive interfaces : M.2, Serial ATA
RAID support : Yes
Supported storage drive types : HDD & SSD
Number of storage drives supported : 6
USB port : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity : 1
Concurrent connections : 2000
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 3
Ethernet LAN (RJ-45) ports : 2
PCI Express x4 (Gen 3.x) slots : 2
Warnings : Do not dispose of the device in the regular rubbish bin. The product requires special disposal., Avoid contact with liquids., Do not dismantle the appliance yourself.
