Description
Processor frequency : 1.7 GHz
Processor manufacturer : Annapurna Labs
Processor model : AL324
Processor cores : 4
Processor family : Annapurna Labs
Internal memory : 4 GB
Memory slots : 1
Memory form factor : UDIMM
Maximum RAM supported : 16 GB
Internal memory type : DDR4
Flash memory : 512 MB
Chassis type : Rack (2U)
LED indicators : LAN, Status, HDD
Cooling type : Active
Fan diameter : 7 cm
Number of fans : 2 fan(s)
Product colour : Black
AC input voltage : 100 – 240 V
Power supply location : Built-in
Power supply unit (PSU) capacity : 250 W
Fan voltage : 12 V
Power consumption (typical) : 69.191 W
Number of power supply units : 2
Operating temperature (T-T) : 0 – 40 °C
Operating relative humidity (H-H) : 5 – 95%
Width : 482 mm
Height : 89 mm
Weight : 10.9 kg
Depth : 534 mm
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Ethernet LAN data rates : 100, 2500, 10000 Mbit/s, 1000 Mbit/s
Supported network protocols : PPTP, L2TP/IPSec, OpenVPN, QBelt
DHCP client : Yes
Link aggregation : Yes
DHCP server : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
WLAN adapter supported : Yes
iSCSI support : Yes
Load balancing system : Yes
Jumbo frames support : Yes
Access Control List (ACL) : Yes
Security algorithms : SSL/TLS, SSH, HTTPS, FIPS 140-2, 256-bit AES
Backup function : Yes
Universal Plug and Play (UPnP) : Yes
Backup features : Cloud, iSCSI LUN
Noise level : 30.6 dB
System log : Yes
Reset button : Yes
Hot spare : Yes
On/off switch : Yes
USB copy function : Yes
Web-based management : Yes
Snapshot : Yes
Device class : Small & Medium Business
Multilingual support : Yes
S.M.A.R.T. support : Yes
Built-in FTP server : Yes
Browser supported : Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome
Type : NAS
Buzzer : Yes
Share folder : CIFS/SMB
Number of screws : 56
Cables included : LAN (RJ-45), AC
Server operating systems supported : Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2008 R2, Windows Server 2019
Windows operating systems supported : Windows 8, Windows 7, Windows 10
Mac operating systems supported : Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.11 El Capitan, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Operating system installed : QNAP Turbo System
Operating system version : 5.0.0
Linux operating systems supported : Yes
RAID levels : 0, JBOD, 6, 10, 1, 5
Supported file systems : HFS+, FAT32, ext4, ext3, NTFS
Supported storage drive types : HDD & SSD
Bad block scan : Yes
Online RAID expansion : Yes
Storage drives installed : No
Storage drive interface : Serial ATA III
RAID rebuild : Yes
RAID support : Yes
Storage drive sizes supported : 2.5, 3.5"
Installed storage drive type : No
Number of storage drives supported : 8
Hot-swap drive bays : Yes
Online RAID migration : Yes
Supported storage drive interfaces : Serial ATA II, Serial ATA III
Fiber ports quantity : 2
Ethernet LAN (RJ-45) ports : 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 4
Concurrent connections : 700
USB port : Yes
Fiber optic connector : SFP+
Harmonized System (HS) code : 84714100
