Description
Processor model : C5125
Processor family : Intel Atom®
Processor manufacturer : Intel
Processor frequency : 2.8 GHz
Processor cores : 8
Memory slots : 4
ECC : Yes
Internal memory type : DDR4
Maximum RAM supported : 128 GB
Flash memory : 5000 MB
Memory form factor : UDIMM
Internal memory : 8 GB
Product colour : Black
LED indicators : HDD, Status, LAN, Power, SSD, USB
Cable lock slot type : Kensington
Fan diameter 2 : 9 cm
Cable lock slot : Yes
Fan diameter : 8 cm
Cooling type : Active
Number of fans : 3 fan(s)
Chassis type : Tower
Number of power supply units : 1
Power supply location : Built-in
Power consumption (typical) : 75.79 W
AC input voltage : 100 – 240 V
Power supply unit (PSU) capacity : 250 W
Operating temperature (T-T) : 0 – 40 °C
Storage temperature (T-T) : -20 – 70 °C
Operating relative humidity (H-H) : 5 – 95%
Height : 231.9 mm
Width : 292.9 mm
Depth : 319.8 mm
Package weight : 10.1 kg
Weight : 8.5 kg
Ethernet LAN data rates : 2500, 100, 1000 Mbit/s, 10, 10000 Mbit/s
Supported network protocols : IPv4, IPv6
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Jumbo frames support : Yes
Dynamic DNS (DDNS) : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
iSCSI support : Yes
DHCP server : Yes
USB copy function : Yes
Access Control List (ACL) : Yes
On/off switch : Yes
Multilingual support : Yes
Security algorithms : SSH, 256-bit AES, HTTPS, FIPS 140-2
Backup function : Yes
Snapshot : Yes
Browser supported : Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Type : SAN
S.M.A.R.T. support : Yes
System log : Yes
Device class : Home & Home Office
Backup features : USB drive, iSCSI LUN
Buzzer : Yes
Share folder : CIFS/SMB
Reset button : Yes
Hot spare : Yes
Built-in FTP server : Yes
Management protocols : SNMP V2, V3
Cables included : LAN (RJ-45), AC
Number of screws : 56
Quick installation guide : Yes
Power cables quantity : 2
Windows operating systems supported : Windows 10 Pro x64, Windows 8 Enterprise, Windows 10 Home, Windows 7 Starter x64, Windows 10 Education x64, Windows 11 Enterprise x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 11, Windows 7 Home Basic, Windows 11 x64, Windows 8 x64, Windows 10 Education, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Home x64, Windows 8, Windows 11 Home, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 7 Professional x64, Windows 11 Enterprise, Windows 11 Pro, Windows 8 Pro, Windows 7 Enterprise, Windows 7 Professional, Windows 7
Operating system installed : QNAP QTS
Linux operating systems supported : CentOS 7.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, SuSE Linux 12.0
Other operating systems supported : IBM AIX 7.2, IBM AIX 7.1, Solaris 10, Solaris 11
Server operating systems supported : Windows Server 2008 R2, Windows Server 2012, Windows Server 2019, Windows Server 2012 R2, Windows Server 2016
Mac operating systems supported : Mac OS X 10.15.3 Catalina, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura, Mac OS X 12.0 Monterey, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.11 El Capitan, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Operating system version : 5.0.1
RAID levels : JBOD, 10, 6, 50, 1, 60, 0, 5
Storage drives installed : No
Supported file systems : ext4, FAT32, ext3, NTFS, HFS+, exFAT
Storage drive sizes supported : 2.5, 3.5"
Supported storage drive types : HDD & SSD
RAID support : Yes
Online RAID migration : Yes
Total installed storage capacity : 0 TB
Supported storage drive interfaces : Serial ATA II, Serial ATA III
RAID rebuild : Yes
Number of M.2 (M & B) slots : 2
Disk roaming : Yes
Installed storage drive type : No
Online RAID expansion : Yes
Hot-swap drive bays : Yes
Storage drive capacity : 0 GB
Number of storage drives supported : 8
USB 2.0 ports quantity : 1
Ethernet LAN (RJ-45) ports : 3
PCI Express x4 (Gen 3.x) slots : 2
USB port : Yes
Concurrent connections : 700
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 3
Fibre Channel : Yes
