Description
CPU configuration (max) : 1
Processor frequency : 2.6 GHz
Processor cores : 8
Processor manufacturer : Intel
Processor threads : 16
Processor boost frequency : 4.8 GHz
Processor family : Intel Xeon E
Processor model : E-2378
Processor cache : 16 MB
Internal memory type : DDR4
Memory form factor : UDIMM
Memory slots : 4
ECC : Yes
Internal memory : 64 GB
Flash memory : 5000 MB
Maximum RAM supported : 128 GB
Cooling type : Active
Product colour : White, Black
LED indicators : Status, LAN, HDD, USB
Chassis type : Rack (4U)
Fan diameter : 8 cm
Number of fans : 4 fan(s)
Power supply location : Built-in
Power supply unit (PSU) capacity : 800 W
Number of power supply units : 2
Operating temperature (T-T) : 0 – 40 °C
Storage temperature (T-T) : -20 – 70 °C
Operating relative humidity (H-H) : 5 – 95%
Package weight : 29.6 kg
Height : 178 mm
Depth : 630 mm
Width : 483 mm
Weight : 21.8 kg
Ethernet LAN data rates : 100, 1000 Mbit/s, 2500
Supported network protocols : IPv4, IPv6
DHCP server : Yes
Ethernet LAN : Yes
Copper ethernet cabling technology : 10GBASE-T
iSCSI support : Yes
Dynamic DNS (DDNS) : Yes
Security algorithms : SNMPv3, HTTPS, SNMPv2, SSH
Backup function : Yes
Number of users : 16000 user(s)
Browser supported : Apple Safari (latest version), Google Chrome (latest version), Microsoft Edge (latest version), Mozilla Firefox (latest version)
Type : NAS
Reset button : Yes
Web-based management : Yes
On/off switch : Yes
Snapshot : Yes
Backup features : Cloud, iSCSI LUN
Access Control List (ACL) : Yes
Multilingual support : Yes
Share folder : Thick, Thin
Hot spare : Yes
System log : Yes
Share folder access right management : Yes
S.M.A.R.T. support : Yes
Disk scan : Yes
Built-in FTP server : Yes
Device class : Large Enterprise Business
Management protocols : SMB/CIFS, AFP, NFS
Cables included : LAN (RJ-45), AC
Quick installation guide : Yes
Power cables quantity : 2
Number of screws : 216
Intel Trusted Execution Technology : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel 64 : Yes
Idle States : Yes
Execute Disable Bit : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Enhanced Intel SpeedStep Technology : Yes
Server operating systems supported : Windows Server 2008 R2, Windows Server 2019, Windows Server 2012 R2, Windows Server 2016, Windows Server 2012
Windows operating systems supported : Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 11, Windows 8 x64, Windows 10 Education, Windows 8 Pro x64, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 7 Ultimate x64, Windows 7 x64, Windows 10 Home, Windows 7 Starter x64, Windows 10 Education x64, Windows 11 x64, Windows 7 Professional, Windows 7, Windows 10 Pro x64, Windows 8 Enterprise, Windows 7 Professional x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 10 Home x64, Windows 8, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 10 Enterprise x64, Windows 10 x64
Other operating systems supported : IBM AIX 7.1, Solaris 10
Mac operating systems supported : Mac OS X 10.15.3 Catalina, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 12.0 Monterey, Mac OS X 10.13 High Sierra, Mac OS X 10.11 El Capitan, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Operating system installed : QuTS hero
Linux operating systems supported : openSUSE 12.2, Ubuntu 14.04, CentOS 7.0, openSUSE 12.1
Operating system version : h5.0.0
RAID levels : 6, JBOD, 5, 50, 60, 10, 1
Number of storage drives supported : 30
Supported storage drive types : HDD & SSD
Storage drive interface : Serial ATA
RAID support : Yes
Installed storage drive type : No
Storage drive sizes supported : 3.5", 2.5
Supported storage drive interfaces : Serial ATA
RAID rebuild : Yes
Disk roaming : Yes
Storage drives installed : No
Supported file systems : ZFS, HFS+, ext4, FAT32, ext3, NTFS, exFAT
System drive sizes supported : 3.5"
Auto-rebuild : Yes
Online RAID expansion : Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity : 4
Ethernet LAN (RJ-45) ports : 4
USB port : Yes
Number of SATA III connectors : 30
PCI Express x8 (Gen 4.x) slots : 1
Fibre Channel : Yes
