Description
Processor threads : 4
Processor model : R1600
Processor cores : 2
Processor manufacturer : AMD
Processor family : Ryzen Embedded
Processor frequency : 2.6 GHz
Processor boost frequency : 3.1 GHz
Processor generation : AMD Ryzen Embedded R1000 Series
Memory form factor : SO-DIMM
Internal memory type : DDR4
Internal memory : 4 GB
ECC : Yes
Maximum RAM supported : 32 GB
Memory slots : 2
Number of fans : 1 fan(s)
Cooling type : Active
LED indicators : Yes
Product colour : Black
Drive bay locking : Yes
Fan diameter : 9.2 cm
Power consumption (typical) : 20.41 W
AC input frequency : 50 – 60 Hz
AC input voltage : 100 – 240 V
Power supply location : External
Power consumption (HDD standby) : 7.87 W
Power supply unit (PSU) capacity : 65 W
Operating relative humidity (H-H) : 5 – 95%
Storage relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 40 °C
Storage temperature (T-T) : -20 – 60 °C
Width : 106 mm
Height : 166 mm
Depth : 223 mm
Weight : 1.51 kg
Ethernet LAN : Yes
Ethernet LAN data rates : 2500 Mbit/s
Wake-on-LAN ready : Yes
Type : NAS
On/off switch : Yes
Noise level : 17.9 dB
Web-based management : Yes
Backup features : iSCSI LUN, Cloud
Multilingual support : Yes
Backup function : Yes
System log : Yes
Device class : Home & Home Office
Snapshot : Yes
Number of users : 512 user(s)
Access Control List (ACL) : Yes
Cables included : LAN (RJ-45), AC
Power cables quantity : 1
External power adapter : Yes
RAID levels : 5, 6, 0, 1, 10, JBOD
Number of storage drives supported : 7
Storage drive sizes supported : M.2, 2.5, 3.5"
Supported storage drive interfaces : M.2, Serial ATA
Supported storage drive types : HDD & SSD
RAID support : Yes
Maximum supported storage capacity : 140 TB
Installed storage drive type : No
Storage drive capacity : 0 GB
Number of M.2 (M & B) slots : 2
Total installed storage capacity : 0 TB
Supported file systems : HFS+, ext3, NTFS, ext4, FAT32, BTRFS, exFAT
Hot-swap drive bays : Yes
Storage drives installed : No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 1
Ethernet LAN (RJ-45) ports : 2
USB port : Yes
Warranty period : 3 year(s)
Compliance certificates : RoHS
