Description
Processor family : Ryzen Embedded
Processor cores : 4
Processor model : V1780B
Processor manufacturer : AMD
Processor frequency : 3.35 GHz
Number of processors supported : 1
Processor generation : AMD Ryzen Embedded V1000 Series
Processor boost frequency : 3.6 GHz
Internal memory type : DDR4
Memory slots : 2
Memory form factor : UDIMM
Maximum RAM supported : 32 GB
Internal memory : 8 GB
ECC : Yes
Chassis type : Rack (2U)
Number of fans : 3 fan(s)
Built-in display : No
Cooling type : Active
Built-in speaker(s) : No
Fan diameter : 6 cm
LED indicators : Yes
Product colour : Black, Grey
Power consumption (typical) : 119.95 W
Redundant power supply (RPS) support : No
Power supply location : Built-in
Number of power supply units : 1
Power supply unit (PSU) capacity : 500 W
AC input voltage : 100 – 240 V
AC input frequency : 50 – 60 Hz
Operating relative humidity (H-H) : 5 – 95%
Operating temperature (T-T) : 0 – 35 °C
Storage temperature (T-T) : -20 – 60 °C
Height : 88 mm
Width : 482 mm
Depth : 562 mm
Weight : 11.5 kg
Copper ethernet cabling technology : 100BASE-TX, 10BASE-T, 1000BASE-T, 10GBASE-T
Ethernet LAN : Yes
iSCSI support : Yes
Ethernet LAN data rate supported (max) : 10000 Mbit/s
Link aggregation : Yes
Ethernet LAN data rates : 100, 10, 10000 Mbit/s, 1000 Mbit/s
Wake-on-LAN ready : Yes
Backup function : Yes
Backup features : Cloud, iSCSI LUN
Noise level : 52.3 dB
Card reader integrated : No
Snapshot : Yes
Multilingual support : Yes
System log : Yes
Type : NAS
Device class : Small & Medium Business
Browser supported : Google Chrome Firefox Microsoft Edge Safari
Built-in FTP server : Yes
Access Control List (ACL) : Yes
Management protocols : SNMP
Security algorithms : AES
External power adapter : No
Cables included : AC
Rack mount kit : Yes
Power cables quantity : 1
Operating system installed : DiskStation Manager
Operating system version : 7.1.1
RAID levels : 6, 0, 1, JBOD, 5, 10
Total installed storage capacity : 0 TB
Online RAID expansion : Yes
Supported file systems : HFS+, Fat, exFAT, ext4, BTRFS, ext3, NTFS
Storage drive sizes supported : 2.5, 3.5"
Installed storage drive type : No
Hot-swap drive bays : Yes
Number of storage drives supported : 12
Online RAID migration : Yes
Storage drives installed : No
Supported storage drive types : HDD & SSD
RAID support : Yes
Supported storage drive interfaces : Serial ATA
PCI Express x8 (Gen 3.x) slots : 1
Ethernet LAN (RJ-45) ports : 3
USB port : Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
Compliance certificates : RoHS, CE
Warnings : Do not dispose of the device in the regular rubbish bin. The product requires special disposal., Do not dismantle the appliance yourself.
Sustainability compliance : Yes
