Synology RackStation RS3618xs NAS Rack (2U) Intel® Xeon® D D-1521 8 GB DDR4 DiskStation Manager Black

Description

Processor threads : 8
Processor code : SR2DF
PCI Express configurations : 1×16, 1×8, 1×4
Processor package size : 37.5 x 37.5 mm
PCI Express slots version : 2.0, 3.0
Processor frequency : 2.4 GHz
Stepping : V2
CPU configuration (max) : 1
Processor boost frequency : 2.7 GHz
Processor manufacturer : Intel
Processor codename : Broadwell
Processor lithography : 14 nm
Conflict-Free processor : Yes
Scalability : 1S
Thermal Design Power (TDP) : 45 W
Processor socket : BGA 1667
Processor cache : 6 MB
Processor family : Intel® Xeon® D
Maximum internal memory supported by processor : 128 GB
Processor model : D-1521
Processor cores : 4
Processor series : Intel Xeon D-1500
ECC supported by processor : Yes
Processor operating modes : 64-bit
Internal memory type : DDR4
Internal memory : 8 GB
Memory slots : 4
Maximum RAM supported : 64 GB
Memory clock speed : 2133 MHz
LED indicators : Power, HDD
Number of fans : 4 fan(s)
Fan diameter : 8 cm
Chassis type : Rack (2U)
Cooling type : Active
Product colour : Black
AC input voltage : 100 – 240 V
Power consumption (typical) : 142.76 W
AC input frequency : 50 – 60 Hz
Power supply location : Built-in
Power supply unit (PSU) capacity : 500 W
Number of power supply units : 1
Power consumption (HDD standby) : 55.05 W
Operating altitude : 0 – 5000 m
Operating temperature (T-T) : 5 – 35 °C
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 60 °C
Height : 88 mm
Depth : 692 mm
Weight : 14.5 kg
Width : 430.5 mm
Supported network protocols : CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN)
Ethernet LAN : Yes
iSCSI support : Yes
Ethernet LAN data rates : 10, 1000 Mbit/s, 100
Link aggregation : Yes
Wake-on-LAN ready : Yes
Wi-Fi : No
Share folder : CIFS/AFP/FTP
Multilingual support : Yes
System log : Yes
Noise level : 50.2 dB
Number of users : 16000 user(s)
Backup features : Cloud, iSCSI LUN
Access Control List (ACL) : Yes
Reset button : Yes
S.M.A.R.T. support : Yes
On/off switch : Yes
Web-based management : Yes
Security algorithms : HTTPS, SSL/TLS, SSH
Browser supported : Chrome, Firefox, Internet Explorer 10, Safari
Hot spare : Yes
Backup function : Yes
Type : NAS
Device class : Small & Medium Business
Cables included : AC
Quick installation guide : Yes
Maximum number of PCI Express lanes : 32
Intel TSX-NI version : 1.00
Intel Enhanced Halt State : Yes
Intel 64 : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Memory channels supported by processor : Dual
Intel Trusted Execution Technology : Yes
Intel TSX-NI : Yes
UART : Yes
Intel® Secure Key : Yes
Embedded options available : No
Execute Disable Bit : Yes
Intel® Turbo Boost Technology : 2.0
Memory types supported by processor : DDR3-SDRAM, DDR4-SDRAM
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel® Hyper Threading Technology (Intel® HT Technology) : Yes
Thermal Monitoring Technologies : Yes
Intel® AES New Instructions (Intel® AES-NI) : Yes
Enhanced Intel SpeedStep Technology : Yes
Idle States : Yes
Intel® OS Guard : Yes
Intel Secure Key Technology version : 1.00
Mac operating systems supported : Mac OS X 10.12 Sierra, Mac OS X 10.11 El Capitan
Mac compatibility : Yes
Operating system installed : DiskStation Manager
Windows operating systems supported : Windows 10, Windows 7
Server operating systems supported : Windows Server 2012 R2, Windows Server 2012
RAID levels : JBOD, 5, 1, F1, 10, 6, 0
Storage drive sizes supported : 3.5", 2.5
Supported file systems : BTRFS, ext4, Fat, ext3, NTFS, HFS+
Number of storage drives supported : 12
RAID support : Yes
Storage drives installed : No
Maximum supported storage capacity : 144 TB
Supported storage drive types : HDD & SSD
Supported storage drive interfaces : Serial ATA, Serial ATA II, Serial ATA III
Installed storage drive type : No
Hot-swap drive bays : Yes
USB port : Yes
Ethernet LAN (RJ-45) ports : 4
PCI Express x8 (Gen 3.x) slots : 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
Processor ARK ID : 91202
Compliance certificates : RoHS
Harmonized System (HS) code : 84714100
