Description
CPU configuration (max) : 1
Processor frequency : 2.2 GHz
Processor family : Intel® Xeon®
On-board graphics card model : Not available
Processor cores : 6
Processor boost frequency : 2.7 GHz
Conflict-Free processor : Yes
Processor manufacturer : Intel
Processor model : D-1531
Maximum RAM supported : 64 GB
Internal memory type : DDR4
Memory form factor : UDIMM
Internal memory : 8 GB
ECC : Yes
Memory slots : 4
Built-in display : No
Cooling type : Active
Chassis type : Rack (2U)
Fan diameter : 8 cm
Built-in speaker(s) : No
Number of fans : 4 fan(s)
Product colour : Black
AC input voltage : 100 – 240 V
AC input frequency : 50 – 60 Hz
Redundant power supply (RPS) support : Yes
Power consumption (typical) : 140.01 W
Power consumption (HDD standby) : 65.94 W
Power supply unit (PSU) capacity : 500 W
Operating temperature (T-T) : 0 – 35 °C
Operating relative humidity (H-H) : 5 – 95%
Storage temperature (T-T) : -20 – 60 °C
Height : 88 mm
Weight : 14.5 kg
Depth : 724 mm
Width : 482 mm
Wake-on-LAN ready : Yes
Ethernet LAN : Yes
Type : Storage server
Noise level : 50.2 dB
On/off switch : Yes
Backup function : Yes
Device class : Small & Medium Business
Power cables quantity : 2
Intel TSX-NI : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
Intel Secure Key Technology version : 1.00
Idle States : Yes
Intel TSX-NI version : 1.00
Intel Enhanced Halt State : Yes
Execute Disable Bit : Yes
Embedded options available : No
Intel Trusted Execution Technology : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel 64 : Yes
Enhanced Intel SpeedStep Technology : Yes
Installed storage drive type : No
Storage drive interface : Serial ATA II, Serial ATA III
Supported storage drive types : HDD & SSD
RAID support : Yes
Storage drive sizes supported : 2.5, 3.5"
Number of storage drives supported : 12
Storage drives installed : No
USB port : Yes
Ethernet LAN (RJ-45) ports : 4
PCI Express x8 (Gen 3.x) slots : 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity : 2
Harmonized System (HS) code : 84714100
