Description
LED indicators : PoE, Activity, Status, Power, Link
Reset button : Yes
Wall mountable : Yes
Housing material : Polycarbonate (PC)
Form factor : Desktop/Wall-Mounting
Product colour : White
DIN rail mounting : Yes
Power supply included : No
Power consumption (max) : 17 W
Power source : AC/DC/PoE
Input current : 3.9 A
DC input voltage : 54 V
Loop protection : Yes
Operating temperature (T-T) : -20 – 45 °C
Operating relative humidity (H-H) : 10 – 90%
Switch type : Managed
Switch layer : L2
Height : 33.5 mm
Width : 212.9 mm
Depth : 99.4 mm
Weight : 567 g
Ethernet LAN data rates : 10,100,1000,2500 Mbit/s
10G support : Yes
Broadcast storm control : Yes
Rate limiting : Yes
Port mirroring : Yes
Flow control support : Yes
Compliance certificates : Federal Communications Commission (FCC), CE, Industry Canada (IC)
10G Ethernet (copper) ports quantity : 1
2.5G Ethernet (copper) ports quantity : 8
Basic switching RJ-45 Ethernet ports quantity : 8
Basic switching RJ-45 Ethernet ports type : 2.5G Ethernet (100/1000/2500)
Power connector : DC-in jack
SFP+ module slots quantity : 1
Jumbo frames support : Yes
Switching capacity : 60 Gbit/s
Forwarding rate : 44.64 Mpps
Throughput : 30 Gbit/s
Power over Ethernet (PoE) power per port : 15.4 W
Total Power over Ethernet (PoE) budget : 196 W
Power over Ethernet (PoE) : Yes
Power over Ethernet (PoE) voltage : 57 V
Power over Ethernet plus (PoE+) ports quantity : 8
Power over Ethernet 4PPoE (PoE++) ports quantity : 1
Multicast support : Yes
